OpenAPI ([docs][openapi-docs], [official spec][openapi-spec])
is a standard format for documenting HTTP APIs. It is
the successor of [Swagger][swagger], also known as OpenAPI 2.

With OpenAPI documentation, you can provide nice interactive docs for
the users of your API ([here's an example using Swagger UI][example]).
They can also automatically generate client code for your API using a
tool like [openapi-generator][openapi-generator] or [the Clojure
library Martian][martian]

[issues]: https://github.com/metosin/reitit/issues
[slack]: https://clojurians.slack.com/archives/C7YF1SBT3
[openapi-spec]: https://learn.openapis.org/specification/
[openapi-docs]: https://spec.openapis.org/oas/v3.1.0
[swagger]: https://swagger.io/
[openapi-generator]: https://openapi-generator.tech/
[martian]: https://github.com/oliyh/martian
[example]: https://petstore3.swagger.io/

## Cool Features in OpenAPI 3

Why should you care about OpenAPI 3 when Swagger works just fine? Some
of the additions that OpenAPI 3 brings might be crucial for
documenting your API properly.

Most significantly, OpenAPI 3 brings full
[JSON Schema](https://json-schema.org/) support. This means that you can
express richer schemas, for example via the operators `oneOf`, `anyOf`
and `allOf`. These operators were present as partially-supported
extensions in Swagger, but in JSON Schema and OpenAPI 3, they have
full support.

Relatedly, you can use _discriminators_ to pick which schema applies
to a value based on a field. This is crucial for big union types like
events. Here's a nice
[blog post on these new features](https://redocly.com/docs/resources/discriminator/).
Note that as of this release, Reitit does not know how to
generate discriminators automatically for you.

OpenAPI 3 also lets you specify different schemas for different
request/response content types. Also, you can specify multiple named
examples for parameters. You can find examples of both of these in the
[Reitit example discussed below](https://github.com/metosin/reitit/tree/master/examples/http-swagger).

On the authentication side, OpenAPI 3 has added support for cookie
parameters & authentication, and better OAuth / OpenID Connect
support. See [the spec](https://spec.openapis.org/oas/v3.1.0#security-scheme-object)
for more info.

## Example

Generating OpenAPI 3 documentation from Reitit is straightforward.
Just use `create-openapi-handler` to define a route. The OpenAPI docs
will be generated based on the route data like `:summary`,
`:parameters`, etc.

```clj
[["/openapi.json"
 {:get {:no-doc true
 :openapi {:info {:title "my-api"
 :description "reitit + openapi3"
 :version "0.0.1"}
 :tags [{:name "api"
 :description "the api"}]}
 :handler (openapi/create-openapi-handler)}}]

 ["/api"
 {:tags ["api"]}

 ["/hello"
 {:get {:summary "hello"
 :handler (fn [_]
 {:status 200
 :body "hello world"})}}]

 ["/plus"
 {:post {:summary "plus with malli body parameters"
 :description "description here"
 :parameters {:body {:x :int, :y :int}}
 :responses {200 {:body {:total :int}}}
 :handler (fn [request]
 (let [{:keys [x y]} (-> request :parameters :body)]
 {:status 200
 :body {:total (+ x y)}}))}}]]]
```

Here's what
[Swagger UI](https://swagger.io/tools/swagger-ui/)
looks like for this API:

<img src="../../img/posts/reitit-openapi-swagger-ui.png">

The
[ring-malli-swagger](https://github.com/metosin/reitit/tree/master/examples/ring-malli-swagger)
and
[ring-spec-swagger](https://github.com/metosin/reitit/tree/master/examples/ring-spec-swagger)
examples in the Reitit repository has been extended to serve OpenAPI 3
& Swagger specs side-by-side. Check them out!

## Migrating A Reitit App to OpenAPI 3

Just like in the previous example, you can easily serve Swagger and
OpenAPI 3 specs side-by-side for a transition period.

To migrate your Reitit app to OpenAPI 3, do the following:

1. Add a `reitit.openapi/create-openapi-handler` route. Here's a minimal example:
```clj
["/openapi.json"
 {:get {:handler (openapi/create-openapi-handler)
 :openapi {:info {:title "my nice api" :version "0.0.1"}}
 :no-doc true}}]
```
2. See how your OpenAPI 3 spec looks like in Swagger UI, and validate
 it using a tool like
 [openapi-schema-validator](https://www.npmjs.com/package/@seriousme/openapi-schema-validator).
3. If you have additional fields under your swagger handler (e.g.
 `:securityDefinitions`), port them to OpenAPI 3 format, and add
 them under the `:openapi` key in the route you just added.
4. If you have custom `:swagger` data on your other routes, convert
 them to `:openapi`
5. Use `:json-schema/default` and `:json-schema/example` in addition
 to `:swagger/default` and `:swagger/example` in your schema metadata.
 - For Plumatic Schema, the new keys are `:openapi/default` and
 `:openapi/example` instead.

## Thanks

It takes a village to raise a library, as they say. I'd like to thank
everybody who made this Reitit update happen.

First of all, thanks to [Solita](https://www.solita.fi) for sponsoring
the delivery of the OpenAPI 3 feature and thus my part of the work.
Without their nudging and financial support, this release would've
happened a _lot_ later.

Secondly, thanks to current and former Metosin programmers
[@ikitommi](https://github.com/ikitommi),
[@Deraen](https://github.com/Deraen),
[@kalekale](https://github.com/kalekale), and
[@miikka](https://github.com/miikka)
for their work on the Metosin libraries
[Reitit](https://github.com/metosin/reitit),
[Malli](https://github.com/metosin/malli),
[Spec-tools](https://github.com/metosin/spec-tools), and
[Schema-tools](https://github.com/metosin/schema-tools).

The foundation of the work was transforming Malli, Spec and Plumatic
Schema schemas into [JSON Schema](https://json-schema.org/), which
OpenAPI 3 builds on.

The initial JSON Schema support for Spec (via spec-tools) and Malli
was implemented by Metosin.

[@rrudakov](https://github.com/rrudakov) contributed OpenAPI support for spec-tools in
[PR #236](https://github.com/metosin/spec-tools/pull/236)
and schema-tools in
[PR #63](https://github.com/metosin/schema-tools/pull/63).

Bringing all of these tools together in Reitit was a long process,
with lots of discussion among the community in
[Reitit issue #84](https://github.com/metosin/reitit/issues/84)
and some valiant first implementation efforts by
[@czan](https://github.com/czan) and
[@Koura](https://github.com/Koura).

Finally, things started to come together last fall when
[@souenzzo](https://github.com/souenzzo)
(from [CyCognito](https://www.cycognito.com/))
submitted an initial version of OpenAPI 3 support in
[Reitit PR #563](https://github.com/metosin/reitit/pull/563)

I picked their work up this spring, added some missing pieces like
docs, tests, and coercion and
[multipart uploads](https://github.com/metosin/reitit/issues/591).

Finally, I wanted to make sure we support mutual recursion of schemas
properly. Luckily,
[@cap10morgan](https://github.com/cap10morgan)
was working on some fixes related to that
[on the Swagger side](https://github.com/metosin/malli/issues/464),
so we could help each other.
[Malli issue #868](https://github.com/metosin/malli/issues/868)
tracks all the fixes I made.

**A big thank you to everybody!**

. Please test it and report any problems on

. We'll have a proper 0.7.0 release soon!
